Copper deficiency is rare but can result from gastrointestinal surgery, excess zinc in the diet, parenteral nutrition, and malabsorption syndromes.1 Copper deficiency gives rise to a sensory ataxic myelopathy, symmetrically involving the pyramidal tracts and dorsal columns in the spinal cord,2 producing a clinical picture indistinguishable from subacute combined degeneration (SCD) associated with vitamin B12 deficiency.1 Brain stem involvement has not been previously reported with copper deficiency. Here we report the first patient with brain stem involvement in copper deficiency myelopathy, demonstrating that it can also be a rhombencephalopathy.
A 47-year-old man with a history of denture cream use insidiously developed bilateral painless vision loss, paresthesias, and quadriparesis over 4 weeks. Neurologic examination revealed left afferent pupillary defect and the presence of optic neuritis. Left upper motor neuron−type facial paralysis, quadriparesis, hyperreflexia, brisk jaw jerk, and a drop sensory level at T6 with graded loss of lower extremity sensation to all modalities were noted. Mild normocytic anemia was present; vitamin B12 and serum zinc were within normal levels. Serum copper (45 mcg/dL; reference range, 70–140 mcg/dL) and ceruloplasmin levels (9 mg/dL; reference range, 17–54 mg/dL) were low. MR imaging of the cervical spinal cord (Fig 1) and brain (Fig 2) is shown. At 6 months, the patient had not responded to copper supplementation and was wheelchair-bound; bilateral optic atrophy had also set in.
A, Sagittal view through the brain stem and cervical spinal cord shows the extent of T2 hyperintensities involving the pyramidal tract and posterior columns (black arrow), extending along the brain stem (white arrow). B, Axial section through the cervical spinal cord shows the strikingly symmetric T2 hyperintense lateral corticospinal tracts and posterior columns. Thoracic spine MR imaging findings were unremarkable (not shown).
MR images of the brain (axial sections, fluid-attenuated reversion recovery sequences) show the symmetric hyperintensities (arrows) involving the pyramidal tract in the (A) medulla, (B) pons, and (C) midbrain.
Copper, an essential trace element required by all life forms, is a component of key metalloenzymes (cytochrome c oxidase, superoxide dismutase, dopamine β hydroxylase), which have a critical role in the structure and function of the nervous system. Given its ubiquitous distribution, dietary copper deficiency is rare but results from causes such as gastrointestinal surgery, zinc excess, malabsorption syndromes, and parenteral nutrition.1 It is associated with symmetric involvement of the pyramidal tract and posterior columns, resulting in a clinical and radiologic picture indistinguishable from SCD2; rarely peripheral neuropathy and optic neuritis have been described.3 Clinical response to treatment is variable.1 To our knowledge, this is the first report of a case that shows striking involvement of the pyramidal tracts in the brain stem, in addition to illustrating typical MR imaging changes of copper deficiency myelopathy. It shows that copper deficiency can be a rhombencephalopathy.
