Abstract
BACKGROUND AND PURPOSE: Conventional MR imaging has high sensitivity but limited specificity in differentiating various vertebral lesions. We aimed to assess the ability of multiparametric MR imaging in differentiating spinal vertebral lesions and to develop statistical models for predicting the probability of malignant vertebral lesions.
MATERIALS AND METHODS: One hundred twenty-six consecutive patients underwent multiparametric MRI (conventional MR imaging, diffusion-weighted MR imaging, and in-phase/opposed-phase imaging) for vertebral lesions. Vertebral lesions were divided into 3 subgroups: infectious, noninfectious benign, and malignant. The cutoffs for apparent diffusion coefficient (expressed as 10−3 mm2/s) and signal intensity ratio values were calculated, and 3 predictive models were established for differentiating these subgroups.
RESULTS: Of the lesions of the 126 patients, 62 were infectious, 22 were noninfectious benign, and 42 were malignant. The mean ADC was 1.23 ± 0.16 for infectious, 1.41 ± 0.31 for noninfectious benign, and 1.01 ± 0.22 mm2/s for malignant lesions. The mean signal intensity ratio was 0.80 ± 0.13 for infectious, 0.75 ± 0.19 for noninfectious benign, and 0.98 ± 0.11 for the malignant group. The combination of ADC and signal intensity ratio showed strong discriminatory ability to differentiate lesion type. We found an area under the curve of 0.92 for the predictive model in differentiating infectious from malignant lesions and an area under the curve of 0.91 for the predictive model in differentiating noninfectious benign from malignant lesions. On the basis of the mean ADC and signal intensity ratio, we established automated statistical models that would be helpful in differentiating vertebral lesions.
CONCLUSIONS: Our study shows that multiparametric MRI differentiates various vertebral lesions, and we established prediction models for the same.
ABBREVIATIONS:
- AUC
- area under the curve
- FNA
- fine-needle aspiration
- GPI
- infectious
- GPN
- noninfectious benign
- GPM
- malignant
- mpMRI
- multiparametric MRI
- SE
- sensitivity
- SIR
- signal intensity ratio
- Sp
- specificity
MR imaging is the preferred technique in the diagnostic work-up of benign and malignant vertebral lesions. Morphologic criteria alone could not differentiate benign and malignant spinal lesions in 6%–21% of cases.1⇓–3 Due to the limited specificity of conventional MR imaging,4 radiologists often have trouble differentiating common spinal pathologies such as osteoporotic vertebral collapse, infectious spondylodiscitis, and metastasis. Recently, multiparametric MR imaging (mpMRI) has shown the ability to localize, detect, and stage various diseases.5⇓⇓–8 The mpMRI approach combines anatomic sequences (T1- and T2-weighted MR imaging) with functional imaging sequences. Functional and quantitative MR imaging methods, such as DWI, dynamic contrast-enhanced MR imaging, and in-phase/opposed-phase imaging, measure the Brownian motion of water molecules, regional vascular properties of the tumor, and fat quantification, respectively.6⇓⇓–9
DWI has been used in the differentiation of benign and malignant spinal lesions.10⇓–12 Signal characteristics of vertebral lesions were evaluated on DWI for qualitative assessment, and the ADC was calculated for quantitative analysis. In general, malignant lesions yield lower ADC compared with noninfectious benign and infectious lesions due to increased cellularity and decreased extracellular space in malignant lesions.10⇓–12 In-phase/opposed-phase MR imaging quantifies fat in tissues and has been used in lesions of the adrenal gland and liver.13⇓⇓⇓–17 It has also been used in diagnostic work-up of spinal lesions, and the results demonstrated a significant difference in the signal intensity ratio (SIR) between benign and malignant vertebral lesions.9,18⇓⇓–21
The hypothesis for this study was that the mpMRI approach would increase the discriminatory ability of different vertebral lesions. The aim of the present study was to evaluate the ability of mpMRI in differentiating vertebral lesions and to establish statistical models for predicting the probability of malignant (GPM) lesions compared with noninfectious benign (GPN) and infectious (GPI) ones. The cutoffs of the ADC and SIR values were obtained to differentiate GPM lesions from GPI and GPN lesions. Furthermore, we considered GPI and GPN as all benign compared with the malignant lesions. The cutoff values of the ADC and SIR for differentiating malignant from all benign lesions were also obtained.
Although attempts have been made to assess the role of quantitative DWI or in-phase/opposed-phase imaging in differentiating vertebral lesions, to the best of our knowledge, no previous study has evaluated the ability of mpMRI to differentiate malignant or infectious lesions from noninfectious benign lesions.
Materials and Methods
Patients and Inclusion Criteria
The institutional ethics committee of King George's Medical University approved this prospective cross-sectional study. All patients gave written informed consent before MR imaging. We included all consecutive patients presenting with vertebral lesions on spine MR imaging between July 2011 and August 2015 who also had CT-guided fine-needle aspiration cytology/biopsy in the absence of trauma. We performed CT-guided fine-needle aspiration (FNA)/biopsy on the basis of clinical indications communicated by the referring department and/or mpMRI findings. We used CT-guided FNA/biopsy (cytohistology/biopsy culture) as a reference standard test. We excluded 9 patients: 5 with motion artifacts and 4 due to indeterminate results of the biopsy. As a result, a cohort of 126 patients was included in the analysis of this study.
The exclusion criteria in the study were patients showing classic features of degenerative changes in the spine, vertebral hemangioma, or innumerable bony metastases. Although the classic cases of Modic degenerative endplate changes were excluded, patients showing signal changes in vertebrae other than the endplates, such as in the region of the vertebral body or posterior elements without any obvious bone destruction, were not excluded. For example, early cases of infectious vertebral lesion or marrow infiltration present as isolated signal changes (marrow edema) without any bone destruction, preparavertebral soft-tissue component, disc involvement, or frank abscess formation were not excluded. The other exclusion criteria were patients with metallic implants, cardiac pacemakers, and claustrophobia; follow-up of vertebral lesions; and postoperative patients. Moreover, patients with abnormal coagulation profiles and those not willing to undergo CT-guided FNA/biopsy were also excluded from the study.
In the study population, 5 patients had a history of other cancers (2 had carcinoma breast, 1 had carcinoma larynx, 1 had carcinoma cervix, and 1 had carcinoma penis). The patient's blood or previous radiologic investigations available at the time of presentation were not collected or analyzed in this study.
MR Image Acquisitions
MR imaging was performed on a 1.5T scanner (Signa Excite; GE Healthcare, Milwaukee, Wisconsin). All patients underwent MR imaging of the spine (T1WI, T2WI, STIR, contrast-enhanced MR imaging, DWI, and in-phase/opposed-phase MR imaging). T1WI in axial (TR/TE = 500/11.7 ms, section thickness = 4 mm) and sagittal planes (TR/TE = 600/10.7 ms, section thickness = 4 mm) was performed. Fast recovery fast spin-echo T2WI (TR/TE = 3400/102 ms, section thickness = 4 mm) in the axial and sagittal planes was performed. The STIR sequence (TR/TE = 3200/110 ms, section thickness = 5 mm, TI = 150 ms) in the sagittal plane was acquired. Phase sequences were obtained in the sagittal plane with the following parameters: in-phase (TR/TE = 118/5 ms; flip angle = 80°), opposed-phase (TR/TE = 118/2.5 ms; flip angle = 80°), section thickness = 5 mm with an intersection gap of 0.5 mm, matrix size = 256 × 160, NEX = 1, FOV = 32 cm, and number of sections = 15.
A single-shot DWI echo-planar sequence was used to acquire data in the sagittal plane: TR/TE = 6200/104.6 ms, b-values of 0 and 600 s/mm2, FOV = 32 cm, section thickness = 5 mm, intersection gap = 1 mm, and NEX = 3. The ADC maps were generated with minimum and maximum b-values.
Contrast-enhanced imaging including non-fat-saturated T1WI (TR/TE = 400/10.8 ms, section thickness = 4 mm) in the axial and sagittal planes was performed. The dosage of gadodiamide (Omniscan; GE Healthcare, Piscataway, New Jersey) contrast given was 0.1 mmol/kg of body weight.
Image Interpretation and Data Analysis
After MR imaging acquisition, images were interpreted prospectively by 2 independent radiologists. All the imaging features, ADC, and SIR values of vertebral lesions were calculated and recorded before the CT-guided FNA/biopsy for each patient. One radiologist had 3 years' experience in neuroradiology and the other had 10 years'. The radiologists were blinded to the patients' clinical information, findings from other imaging modalities, and blood investigations, if any. However, the history of other cancers was available to the radiologists. Due to increased incidence of infectious vertebral lesions in our setup,22 various lesions were classified into 3 subgroups as GPI, GPN, and GPM.
On conventional MR imaging, lesions were primarily vertebral in nature, involving the vertebral body, the posterior elements, or both. We observed associated preparavertebral and/or intraspinal (epidural) soft-tissue components in many of them, but none of the patients had intradural extramedullary or intramedullary involvement.
Mean ADC and SIR were calculated with the ADC map and in-phase/opposed-phase images, respectively. Circular ROIs were drawn on the ADC and in-phase/opposed-phase images manually 3 times within the lesion, and the averages of these values were calculated and used. Although ROIs were not drawn on conventional MR images, T1WI, T2WI, and postcontrast T1WI were used in defining the anatomic landmarks. Also, DWI was used for placement of ROIs at the region with lowest signal on the ADC image. We attempted to keep the ROI locations the same for the ADC and SIR calculations, guided by conventional MR images. The average size of manually drawn ROIs was 20–30 mm2. The ROIs were drawn on the solid, preferably enhancing, bony components of the lesion, avoiding paravertebral soft tissue/collection, if present. The areas of hemorrhage, necrosis, and calcification were avoided. Hypointense signals on T2-weighted and hyperintense signals on T1-weighted images were assumed to indicate hemorrhage/calcification. Furthermore, nonenhancing hypointense areas on T2- and T1-weighted images were considered calcifications. Nonenhancing hyperintense areas similar to fluid on T2-weighted and hypointense areas on T1-weighted images were used for necrosis. Care was taken to exclude endplates, cortical margins, disc spaces, or adjacent normal marrow while drawing the ROIs.
The ADC values were expressed in 10−3 mm2/s. For the calculation of SIR, the signal intensity was measured on in-phase and opposed-phase images in the affected vertebrae. The mean SIR was calculated by dividing the marrow signal intensity recorded on opposed-phase by the in-phase images.
Reference Standard Test
In this study, lesions were identified on mpMRI examinations followed by CT-guided FNA/biopsy from the representative lesions. However, the decision for biopsy was not based merely on the results of mpMRI analysis but also included other clinical parameters for appropriate patient management. The radiologist who interpreted MR images subsequently performed the CT-guided FNA/biopsy on the preselected target vertebra.
The vertebral FNA/biopsy specimen was obtained from 1 vertebra/contiguous soft tissue. A patient may have had >1 type of lesion. However, we recorded 1 type of lesion for each patient when cytohistology was performed. The mean time interval between MR imaging and CT-guided FNA/biopsy was 5 days (range, 3–7 days). If the results of the CT-guided FNA were indeterminate, a repeat CT-guided biopsy was performed in another 6 days (range, 5–8 days). None of the patients underwent open biopsy.
Statistical Analysis
We used previously published data to estimate the sample size for this study. In previous studies, the mean ADC values were reported for the benign group as 1.75–1.98 SD 0.30–0.44; for the infectious group, as 0.91–1.54 SD 0.14–0.38; and for the malignant group, as 0.5–0.77 SD 0.23–0.30.23,24 On the basis of these data, we estimated a sample size of 19 per group to detect significant differences in mean ADC values between GPN and GPI and 34 per group to detect significant differences in mean ADC values between GPI and GPM with >80% power at the 5% level of significance using a 2-sided unpaired t test. Thus, we proposed to include at least 20 cases of GPN, 40 cases of GPI, and 40 cases of GPM. The proposed sample size is more than sufficient to detect differences in mean SIR values between benign and malignant cases on the basis of the data previously reported in studies.9,20 The sample size is also sufficient to develop predictive logistic regression models to differentiate these groups.
Quantitative data were described with mean ± SD and range, while categoric data were presented using frequency and proportion. A weighted κ agreement along with the 95% confidence interval was estimated between 2 independent radiologists. The average ADC and SIR values were compared among 3 groups by using 1-way analysis of variance followed by the Bonferroni correction for multiple comparisons in post hoc analysis. The thresholds of the ADC and SIR in classifying different disease groups were calculated with receiver operating characteristic analysis. The cutoff was selected where the maximum Youden index (sensitivity + specifity − 1) and the minimum distance on the receiver operating characteristic curve from points 0 and 1 were observed. The performance of the cutoff was summarized using sensitivity (SE), and specificity (Sp). The area under the curve (AUC) was summarized to evaluate the overall discriminatory ability of different tests. The likelihood ratios (positive likelihood ratio and negative likelihood ratio) and correct classification measures were also reported for the obtained cutoffs. The receiver operating characteristic curves were constructed for important findings. The individual and combined predictive models of ADC and SIR in differentiating disease groups were developed using logistic regression analysis. Furthermore, the discriminatory performance of the model was summarized with the area under the receiver operating characteristic curve along with the 95% CI. The 95% CI for the AUC was obtained with an asymptotic normal distribution approach. We also conducted internal validation of the developed models by using leave-one-out methods. The indices for model performance were reported for both original and validation analysis. A value of P < .05 was significant. All the statistical analyses were performed with STATA 12.1 (StataCorp, College Station, Texas).
Results
A total of 126 subjects (73 men [57.9%], 53 women [42.1%]; mean age, 45.3 ± 15.2 years, range, 4–76 years) were analyzed. Of the total, 49% (62/126) had GPI lesions, 18% (22/126) had GPN lesions, and 33% (42/126) had GPM lesions using the reference standard. In malignancy, 85.7% (36/42) of cases were metastatic (solitary, 25; multiple, 11) and the remaining 14.2% (6/42) were primary bone tumor. Excellent agreement was obtained on the data generated by the 2 independent radiologists (κ agreement = 0.96; 95% CI, 0.94–0.97).
Most of the patients in the GPI subgroup had tuberculosis, 82% (51/62); the rest of the cases were pyogenic in nature, 18% (11/62), while in the GPN subgroup, most had osteoporotic vertebral collapse, 63% (14/22). The different types of lesions are summarized in On-line Table 1. The morphologic and quantitative imaging of GPI, GPN, and GPM lesions is shown in Figs 1⇓–3, respectively. On-line Fig 1 is a GPN lesion with a histopathologic diagnosis of inflammatory pseudotumor.
A 35-year-old man with biopsy-proved vertebral tuberculosis shows diffusely hypointense signal in the L4 and L5 vertebrae on sagittal T1WI (A) and hyperintense signal on sagittal T2WI (B). The intervening disc space has a small amount of prevertebral and epidural soft tissue. Heterogeneous enhancement of both the involved vertebrae, intervertebral disc space, and prevertebral and epidural soft tissue is noted on the contrast study (C). The lesion is mildly hyperintense on DWI (D). ADC measured from the L5 vertebral body is 1.2 × 10−3 mm2/s (E). Sagittal in-phase (F) and opposed-phase (G) images with the ROI cursor drawn in the lesion are shown. The measured SIR is 0.88.
A 63-year-old woman with biopsy-proved osteoporotic vertebral collapse of the L1 vertebra shows partial collapse of the vertebra with retropulsion of the posterosuperior part of the vertebral body, the presence of the fluid sign, and the absence of prevertebral and epidural soft tissue on T1WI (A) and T2WI (B). The collapsed vertebra shows diffuse heterogeneous enhancement on the contrast study (C). Sagittal DWI obtained at the same level shows isointense signals (D). ADC measured from the LI vertebral body is 1.3 × 10−3 mm2/s (E). Sagittal in-phase (F) and opposed-phase (G) images with the ROI cursor drawn in the lesion are shown. The measured SIR is 0.56.
A 55-year-old man with biopsy-proved vertebral metastasis from transitional cell carcinoma of the D6 vertebra shows an isointense lesion at the D6 vertebra on sagittal T1WI (A) and sagittal T2WI (B). The lesion shows diffuse enhancement on the contrast study (C). The lesion is hyperintense on DWI (D). ADC measured from the lesion is 0.92 × 10−3 mm2/s (E). Sagittal in-phase (F) and opposed-phase (G) images with the ROI cursor drawn in the lesion are shown. The measured SIR is 0.96.
The mean ADC value was 1.23 ± 0.16 for GPI, 1.41 ± 0.31 for GPN, and 1.01 ± 0.22 for GPM lesions (On-line Table 2). The SIR was 0.80 ± 0.13 for GPI, 0.75 ± 0.19 for GPN, and 0.98 ± 0.11 for GPM lesions (On-line Table 2). Overall, the mean ADC and SIR values for 3 different categories of vertebral lesions were significantly different (P < .000 and P < .000). For the ADC values, a statistically significant difference was observed between GPI and GPN lesions (P < .002), GPI and GPM lesions (P < .000), and GPN and GPM lesions (P < .000). In the post hoc analysis of the SIR comparison, a statistically significant difference was observed between GPI and GPM lesions (P < .000) and between GPN and GPM lesions (P < .000). However, for GPI and GPN lesions, the difference was not statistically significant (P = .46) (On-line Table 2).
The diagnostic accuracy of MR imaging quantitative traits for characterizing different vertebral lesions and the results of receiver operating characteristic analysis are summarized in On-line Table 3. The cutoff for ADC to differentiate GPN and GPM lesions was found to be 1.2 with a sensitivity of 86.4% and a specificity of 78.6%. The cutoff for ADC was 1.0 (with an SE of 96.8% and an Sp of 69.1%) in differentiating GPI and GPM lesions, whereas the cutoff for ADC in differentiating GPI and GPN lesions was found to be 1.3 with an SE of 72.7% and an Sp of 59.7% (On-line Table 3). The AUC for the ADC model in differentiating GPN and GPM lesions was 0.89 (95% CI, 0.81–0.96) followed by 0.82 (95% CI, 0.73–0.92) for differentiating GPI and GPM lesions. The cutoffs for SIR in differentiating various categories are depicted in On-line Table 3. The cutoff for SIR was 0.91 with an SE of 85.7% and an Sp of 85.5% in differentiating GPI and GPM lesions, and the SIR model provided an AUC of 0.90 (95% CI, 0.84–0.96). Differentiating GPN and GPM lesions with the SIR cutoff value as 0.90 correctly classified 84.3% cases, and the calculated AUC was 0.86 (95% CI, 0.76–0.97). The ADC cutoff for differentiating all benign from malignant lesions was estimated to be 1.0, whereas the SIR cutoff was estimated to be 0.91 for differentiating malignant lesions from all benign lesions. On-line Fig 1 represents a case with an expansile lesion with endplate erosion and mild homogeneous contrast enhancement. These findings favored a malignant etiology, while its ADC was 1.3 × 10−3 mm2/s and the SIR was 0.64. These features pointed to a benign lesion, which proved to be an inflammatory pseudotumor on histopathology.
With estimated cutoffs for the ADC and SIR, 28 lesions (22.2%) had contradictory ADC and SIR in differentiating malignant from all benign lesions. In these cases, the sensitivity and specificity of ADC values were found to be 26.7% and 92.3%, respectively. Whereas, the sensitivity and specificity of SIR were found to be 73.3% and 7.7%, respectively. Therefore, the joint evaluation of the ADC and SIR values could improve classifications. In differentiating all groups, 45 (35.7%) lesions had different results between ADC and SIR. Overall, misclassification was found to be similar with the ADC and SIR values.
Multivariable logistic regression analysis showed that the ADC and SIR values were significantly associated with GPM compared with GPN or GPI lesions and all benign lesions (On-line Table 4). The AUC for the statistical model (model 1) with ADC and SIR to differentiate GPM from GPI lesions was found to be 0.92 (95% CI, 0.87–0.97), while the AUC for the statistical model (model 2) with ADC and SIR to differentiate GPM from GPN lesions was observed to be 0.91 (On-line Fig 2). The AUC for differentiating malignant lesions from all benign lesions (model 3) was 0.92 (95% CI, 0.87–0.97). The probability of malignant lesions in model 1 can be obtained as exp(−10.50 − 5.67 × ADC + 18.35 × SIR) / [1 + exp(−10.5 − 5.67 × ADC + 18.35 × SIR)]. Moreover, the probability of malignant lesions in model 2 can be obtained by using the equation, exp(−5.93 − 4.59 × ADC + 13.33 × SIR) / [1 + exp(−5.93 − 4.59 × ADC + 13.33 × SIR)]. The probability of malignant lesions compared with all benign lesions in model 3 can be estimated by using the following equation: exp(−8.25 − 5.42 × ADC + 15.27 × SIR) / [1 + exp(−8.25 − 5.42 × ADC + 15.27 × SIR)]. The model validation on the test data (using the leave-one-out method) showed an AUC of 0.91 for model 1, an AUC of 0.88 for model 2, and an AUC of 0.90 for model 3 (On-line Table 4).
Model 1 can differentiate GPI and GPM lesions. A cutoff of 0.39 for model 1 provided the positive likelihood ratio of 4.18. The proposed model 1 achieved a sensitivity of 81% and a specificity of 80.7% at the determined cutoff. This model correctly characterized 81% of cases. Model 2 differentiates GPN and GPM lesions. A cutoff value of 0.68 was determined for the second model; it differentiated GPN and GPM lesions with a high sensitivity and specificity (83.3% and 81.8%, respectively), and it correctly characterized 83% of cases. The positive likelihood ratio for model 2 was 4.58. Model 3 differentiated malignant compared with all benign lesions. A cutoff value of 0.32 for this model provided the positive likelihood ratio of 4.67 with a sensitivity of 83.3% and specificity of 82.1%, and it correctly characterized 82% lesions. (On-line Table 5).
Discussion
A vertebral lesion may be diagnosed with x-ray, CT, and other imaging modalities such as hybrid single-photon emission CT. Among all imaging techniques available, MR imaging is the method of choice in spinal pathology because of its excellent tissue contrast.10,23 Overdiagnosis due to the limited specificity of conventional MR imaging puts patients at risk of unnecessary investigations and delays proper treatment.24,25 Furthermore, spinal tuberculosis, which mimics a malignant condition, is a frequent diagnosis in our experience.22 It is challenging to distinguish atypical variants of spinal tuberculosis from malignancy, especially in the early stage when the isolated vertebral body does not involve any soft-tissue component, adjacent disc involvement, or abscess formation.
Quantitative parameters derived from the mpMRI approach using a combination of DWI and in-phase/opposed-phase imaging could improve patient management. In this study, we have presented 3 statistical models for predicting the probability of malignant vertebral lesions for proper patient management using the mpMRI methods.
DWI has been used previously in various diseases.26⇓⇓–29 Initial studies showed that qualitative DWI offers no advantage over conventional unenhanced MR imaging in the detection of vertebral lesions.10⇓–12,30 Quantitative DWI studies using ADC maps also showed overlapping results in differentiating various vertebral lesions.31,32 Balliu et al32 reported no significant difference in ADC values for differentiating infectious and malignant lesions. In contrast, our study showed a significant difference in ADC values of malignant and infectious vertebral lesions, which could help differentiate malignant and benign vertebral lesions. We observed the lowest ADC values for malignant lesions, the highest ADC values for noninfectious benign lesions, and values in the intermediate range for infectious lesions. A similar trend of ADC values for malignant, acute benign, and infectious vertebral lesions was observed by Dewan et al.33 However, in contrast to our study, they observed overlapping mean ADC values between tuberculous spondylodiscitis and malignant compression fracture. Palle et al31 reported considerable overlap of ADC values in metastatic and tubercular vertebrae. The cutoff value of the ADC determined in our study could be helpful in differentiating various vertebral lesions. An important aspect of the present study is the method of ROI placement and the relatively larger patient population. In contrast to the ADC calculation method used in previous studies, the circular ROIs were placed at the site of maximum restriction observed on the ADC images in this study.33 Furthermore, using the established cutoff in our study, we could achieve higher sensitivity, specificity, and AUC for various predictive models in differentiating vertebral lesions. We could correctly classify >80% of various vertebral lesions using the different statistical models.
In-phase/opposed-phase imaging quantifies fat in tissues because water and fat protons have different precession frequencies and are in-phase at a TE of 4.8 ms and are 180° opposed at a TE of 2.4 ms at 1.5T. The presence of both fat and water in normal marrow results in suppression of signal intensity on the opposed-phase images. In benign compression fractures, no marrow-replacing process occurs, so there is signal loss in opposed-phase images. In case of malignant lesions, the bone marrow fat is replaced by tumor cells, so there is a lack of signal loss on opposed-phase images. Therefore, a substantial decrease in signal intensity occurs in normal vertebrae and for benign lesions, but malignant lesions exhibit either a minimal decrease or an increase in signal intensity.34
A similar trend in our study was also observed. The mean SIR in this study was found to be highest in malignant lesions and lowest in the noninfectious benign lesions. We found that the SIR of affected vertebrae was 0.80 in infectious vertebral lesions, 0.75 in noninfectious benign lesions, and 0.98 in malignant lesions. An optimal cutoff value of SIR was also calculated to differentiate infectious, noninfectious benign, and malignant vertebral lesions. We could differentiate noninfectious benign and malignant vertebral lesions as well as infectious and malignant vertebral lesions with a high sensitivity and specificity using cutoffs for the SIR value of 0.90 and 0.91, respectively. This result coincides with the results of previous studies performed with in-phase/opposed-phase imaging in vertebral lesions.9,20 Disler et al20 reported a relative SIR of 1.03 ± 0.13 for the neoplastic group and 0.62 ± 0.13 for the non-neoplastic group, and a ratio cutoff value of 0.81 resulted in a 95% sensitivity and a 95% specificity for detection of neoplasms. Erly et al9 reported that the mean SIR for benign lesions was 0.58 compared with a malignant lesion cutoff of 0.98, and if 0.80 was chosen as a cutoff, it correctly identifies malignant and benign lesions with a sensitivity of 0.95 and a specificity of 0.89.9 Our findings are consistent with those in that previous study.9
A major strength of this study was developing statistical models for malignant vertebral lesions using mpMRI and determining thresholds for different parameters of mpMRI. Multivariate logistic regression analysis showed ADC and SIR as independent predictors of malignancy in vertebral lesions. On the basis of the mean ADC and SIR, we established automated statistical models that would be helpful in differentiating vertebral lesions. Various predictive models demonstrated excellent validation with leave-one-out analysis.
Our study has several limitations. We recruited patients irrespective of their duration of symptoms (ie, both acute and chronic cases of vertebral lesions) because most of the patients in our institution had poor socioeconomic status and there is a tendency to avoid the costly investigations until later in the disease progression. Another limitation was the modest number of noninfectious benign cases compared with infectious and malignant vertebral lesions. Spinal tuberculosis is more common and a major public health hazard in developing nations such as India, and a similar proportion of the infectious group was reflected in our study. Osteoporotic compression forms a large proportion of noninfectious benign group and is more likely to be managed conservatively. Such patients are less likely to undergo biopsy and hence are under-represented in our study population. The ADC and SIR values were recorded before the CT-guided FNA/biopsy. Because the same radiologists were involved in biopsy procedures as well, performance bias cannot be ignored completely. Although all the models established in this study provided high accuracy in differentiating various vertebral lesions, the output of models needs to be externally validated in a larger study; therefore, future prospective studies are warranted.
Conclusions
Our study shows that mpMRI can differentiate various vertebral lesions. The prediction model established in this study using mpMRI can be used to assess the probability of malignancy in vertebral lesions and may help in accurate diagnosis and proper patient management. The potential utility of statistical models using mpMRI requires further prospective validation.
