Minimally Invasive Ablation of a Toxic Thyroid Nodule by High-Intensity Focused Ultrasound

Discussion

Definitive treatment is always indicated in AFTNs with overt hyperthyroidism and is often recommended for patients with AFTNs and subclinical hyperthyroidism because of the risk of progression to overt hyperthyroidism.^1,2 Radioiodine is a cost-effective and safe procedure and the first choice of therapy for most patients with AFTNs. However, patients are somewhat reluctant to undergo this procedure in view of the policies and recommendations for reducing radiation hazards. Surgery may be preferred in young patients to avoid radiation exposure. The risks of surgery (vocal cord palsy, unavoidable scar, and general anesthesia) have to be taken into consideration.

Despite the small nodule size and normal FT₄ and FT₃, the treatment decision for our patient was based on the clinical symptoms, nodule autonomy, TSH suppression, and the risk of future overt hyperthyroidism.

Radioiodine and surgery were both considered. The low iodine uptake, likely caused by transient iodine overload, did not favor radioiodine use. Surgery was not indicated because of the small size of the nodule and the patient's reservation toward surgery. Alternative treatments, such as ethanol injection,^3,4 laser,^6,12,13 or radio-frequency ablation,⁵ have been reported. Thyroid function is normalized after ethanol injection in approximately 60%–80% of pretoxic nodules and 35%–85% of toxic nodules.³ Tarantino et al⁴ reported complete cure (absent uptake in the nodule and recovery of normal uptake in the thyroid parenchyma) in 93% of patients with AFTNs. After laser ablation, cure rates of 61%–100% have been reported.^6,13 Radio-frequency ablation has also been suggested as a potential nonsurgical therapeutic option.⁵

These procedures are all minimally invasive, requiring, in the case of radio-frequency ablation, the insertion of electrodes into the thyroid nodule and at least 1.5-cm safety margins around the surrounding organs.¹² These treatments often require repeat injections or sessions to achieve total cure, especially in the case of large nodules.¹² Our procedure simply required local intranodular anesthetic, only 2-mm safety margins, and a single 15-minute HIFU session.

With only 1 case, it is too early to compare complication rates between HIFU and other techniques. A complication rate of 3.2%, including vocal cord palsy, abscess, and hematoma, was reported for percutaneous ethanol injection.⁴ In our preliminary animal study, some injuries to neighboring organs, such as skin, trachea, esophagus, and recurrent nerves, were observed; however, the device we used in these studies was not fully suited for this purpose.¹¹ In other clinical applications of HIFU, skin burns and bowel infarction have been reported.^14,15 Morbidity needs to be assessed on a larger scale. Due to stringent inclusion criteria regarding TSH, the tight deadlines of this pilot study, and the subsequent lack of participants, patient enrollment had to be stopped.

In conclusion, this is the first report of the cure of a small AFTN by using HIFU with excellent clinical, biologic, ultrasonographic, and scintigraphic results at 18 months. This case suggests the feasibility and effectiveness of a technique that is safely repeatable in patients with larger nodules. Although further evaluation is needed to confirm these results, this ambulatory, minimally invasive treatment seems to be a promising therapeutic alternative in clinical settings. Advantages over standard therapies would appear significant in terms of cost and morbidity.
