Intracranial and Subcutaneous Lipoma Associated with Sagittal Sinus Fenestration and Falcine Sinus

Case Report

A 5-month-old girl was referred to our hospital with a midline parietal subcutaneous mass noticed at birth. On physical examination, the patient had a rounded soft tissue mass that measured 4 × 3 cm with no hair on its surface. Neurologic examination and routine laboratory studies were normal.

Unenhanced cranial CT showed a hypoattenuated mass in the posterior interhemispheric fissure, extending to the subcutaneous mass through cranium bifidum with attenuation characteristics of adipose tissue (−120 HU). The intracranial part of the mass had a central linear calcification extending to the bone defect. On contrast-enhanced CT, the lesion did not enhance, but duplication of superior sagittal sinus by the mass was observed (Fig 1).

• Download figure
• Open in new tab
• Download powerpoint

Fig 1.

Contrast-enhanced CT shows subcutaneous lipoma and interparietal lipoma with central calcification. Note the duplication of sagittal sinus (arrows) and the defect in the parietal bone.

MR images revealed a posterior interhemispheric mass lesion, hyperintense on T1-weighted image (Fig 2) and hypointense on fat-suppressed T2-weighted image, consistent with lipoma. The lesion was extending to a subcutaneous lipoma through a defect in the parietal bones. Within the inferior part of the intracranial lipoma, a round mass, isointense on T1-weighted image and hyperintense on fat suppressed T2-weighted images, was present, which was thought to be parenchymal tissue. The mass located within the lipoma had a connection with the tectum stretching it posteriorly and superiorly (Fig 2). The intracranial lipoma also had a central linear hypointense area on both T1- and T2-weighted images, representing calcification, extending to the subcutaneous lipoma. The supracerebellar cistern was enlarged as a result of the high location of midline tentorium. There was no other abnormality on MR examination. On MR venography, sagittal sinus fenestration was observed at a site corresponding with that of the defect in the parietal bones beneath the subcutaneous lipoma. The falcine sinus was present in the midline draining to the superior sagittal sinus anterior to the fenestration. The straight sinus was absent. The torcula was in the normal position.

• Download figure
• Open in new tab
• Download powerpoint

Fig 2.

T1-weighted sagittal MR image shows interhemispheric lipoma extending to subcutaneous lipoma through a bone defect. The isointense lesion within the inferior part of the lipoma had a connection with tectum stretching it posteriorly and superiorly.

Discussion

Intracranial lipomas are rare, forming 0.06%–0.46% of intracranial lesions.¹ Interhemispheric fissure is the most common site accounting for more than half of cases.² Interhemispheric lipoma associated with subcutaneous lipoma is extremely rare. Different communication patterns can be observed between intracranial and extracranial components of the lipoma. They may have no connection,⁶ may connect to each other by fibrous-lipomatous stalk,^7,8 or may have direct continuity with each other through cranium bifidum.⁹ There is difficulty in the explanation of extracranial extension of the intracranial lipoma via cranium bifidum. Truwit and Barkovich¹⁰ suggested that extension of the intracranial lipoma to subcutaneous lipoma with cranial dysraphism might have resulted from secondary dehiscence of the cranium with potential evagination of a small tuft of meninx primitiva. This suggestion may explain the diversity of the connection between the intracranial and subcutaneous lipoma. If the scalp defect remains, intracranial lipoma will be continuous with a subcutaneous lipoma, whereas closure of the skull defect would lead to the intraextracranial lipoma being isolated completely.

A variety of vascular abnormalities have been described in association with intracranial lipoma, including distension, kinking, or narrowing of arteries and veins; engulfment of the cerebral arteries; arteriovenous malformation; and aneurysm.¹¹ Our patient had no such abnormalities but had a vertically oriented falcine sinus, absent straight sinus, and sagittal sinus fenestration, which have not been reported before in association with the lipoma.

Superior sagittal sinus and transverse sinus appear as the primitive marginal sinus on approximately the 35th embryonal day. Left and right primitive marginal sinuses join together at the midline on approximately the 50th embryonal day, followed by formation of the superior sagittal sinus at approximately 10 weeks’ gestation.¹² It could be suggested in our case that interhemispheric lipoma with subcutaneous extension was present between primitive marginal sinuses during the fusion. The lack of sagittal sinus fenestration in other reported cases of the intraextracranial lipoma may be due to anatomic location and/or time of the appearance of the lipoma. In patients with normal sagittal sinus, lipoma may appear in the interhemispheric fissure after the fusion of the marginal sinuses, or, if present before the fusion, it may be located lateral to marginal sinuses.

The falcine sinus is a normal accessory sinus, usually obliterated by birth. In the absence of straight sinus, it is not surprising to see the falcine sinus as an alternative venous drainage joining the sagittal sinus in a high position. The alternative venous drainage is variably believed to either represent a falcine sinus^3,4,13 or the straight sinus in an embryonic position.⁵ In our case, we thought that interhemispheric lipoma or the insult that lead to lipoma interfered with the development of the straight sinus, and the falcine sinus remained as an alternative venous drainage.

Similar venous, tentorial, and bone anomalies are present in our case and parietal atretic cephalocele, raising the possibility that anomalies in the present case and parietal atretic cephalocele may represent different spectra of the same developmental anomaly. Calvaria, intracranial venous system, tentorium, and dura are formed from mesenchyme, which is why it is presumed that a mesenchymal disturbance could be the primary cause for the bone, vascular, and tentorial abnormalities.¹³ Superior sagittal sinus, straight sinus, tentorium, and parietal bones are located at the midline on the sagittal plane at the level of the interparietal suture. Therefore, any insult to mesenchyme in this location may lead to anomalies on these structures.

In conclusion, intracranial lipoma with subcutaneous component is a very rare pathology. MR examination must be considered for those infants who have subcutaneous scalp lipoma to evaluate for a possible intracranial component and vascular anomalies, which are important when a surgical procedure is contemplated.
